The Elo 1502L Touchscreen Monitor is designed with the same seamless style that spans across the entire line up of 02-Series Monitors. With a compact form factor and flexible mounting options, Elo's 1502L is well-suited for POS, self-service, signage and customer-facing point of interaction. With a variety of peripherals, the monitor can be transformed to meet the demands of almost any blueprint. The Elo 1502L 15.6-inch touchscreen monitor delivers a professional-grade interactive solution featuring Elo's industry-leading TouchPro PCAP technology with edge-to-edge glass enabling up to 10 simultaneous touches. Backed by a three-year warranty, the feature rich monitor offers a sleek, low-profile, commercial-ready solution with dual built-in speakers and USB Type B or C (depending on the model), VGA and HDMI video connectors. Designed for commercial use, the 1502L simplifies business operations by delivering energy efficiency and versatile accessory options - from EMV and MSR payment devices to a barcode scanner and customer facing display.

Elo E318746 Overview

The Elo M-Series 1502L widescreen LED touch monitor is a modern and stylish interactive solution for customer engagement and employee effectiveness at the point of sale. The sleek wide aspect ratio touchscreen features full HD edge-to-edge glass with display area real estate to showcase engaging, memorable and rewarding content. An HD display model is available for transactional and other applications not requiring 1920x1080 resolution. For environments where space is scarce, the 1502L is an ideal POS terminal screen or stylish interactive information display. Built to withstand the rigors of continuous public use, the 1502L is well suited for high use retail venues. The sleek, thin look pairs well with any modern store environment.

Technical Information

Screen Size Class:

16"

Viewable Screen Size:

15.6"

Screen Mode:

HD

Panel Technology:

Thin Film Transistor (TFT)

Response Time:

10 ms

Aspect Ratio:

16:9

Horizontal Viewing Angle:

90°

Vertical Viewing Angle:

65°

Mount Type:

Wall Mountable

Pole Mount

Placement:

Tabletop

Backlight Technology:

LED

Features:

Anti-glare

On-screen Display (OSD)

Security Lock

Landscape/Portrait Viewable

Cable Lock Slot

Horizontal Frequency:

31.50 Hz to 60 Hz

Vertical Frequency:

60 Hz

Adjustable Stand Height:

Yes

Stand Adjustments:

Height

Curved Screen:

No

Number of OSD Languages:

8

Supported Graphics Resolutions:

640 x 480 (VGA)

720 x 576

800 x 600 (SVGA)

1024 x 768 (XGA)

1280 x 1024 (SXGA)

1280 x 720 (HD 720)

1280 x 800 (WXGA)

1280 x 960

1360 x 768 (WXGA)

1366 x 768

Video

Maximum Resolution:

1366 x 768

Color Supported:

262,000 Colors

Contrast Ratio:

600:1

Native Contrast Ratio:

700:1

Brightness:

220 Nit - LCD Panel

187 Nit - PCAP

Audio

Speakers:

Yes

Number of Speakers:

2

Speaker Output Power:

4 W

Touchscreen Information

Touchscreen:

Yes

Touchscreen Type:

IntelliTouch Pro Projected Capacitive

Multi-touch Screen:

Yes

Number of Simultaneous Touchpoints:

10

Interfaces/Ports

HDMI:

Yes

USB:

Yes

VGA:

Yes

Number of HDMI Inputs:

1

Built-in Devices

Built-in Devices:

Speaker

Webcam:

No

Microphone:

No

Power Description

Operating Power Consumption:

10.20 W

Standby Power Consumption:

500 mW

Off-Mode Power Consumption:

200 mW

Energy Consumption per Year:

18 kWh

Physical Characteristics

VESA Mount Compatible:

Yes

VESA Mount Standard:

100 x 100

Color:

Black

Height:

9.6"

Width:

15.2"

Depth:

1.3"

Weight (Approximate):

6.61 lb

Weight with Stand (Approximate):

6.72 lb

Miscellaneous

Mean Time Between Failures (MTBF):

5.7 Year

Item Numbers

GTIN: 0058293886078, 0834619009006

UPC: 058293886078, 834619009006

EAN: 0058293886078, 0834619009006

UNSPSC: 43211903
